Engineering
Validated by Engineering, Not Marketing
Structural performance has been evaluated through engineering calculations, simulations, and physical testing in cooperation with Kaunas University of Technology.
KTU structural verification
Structural performance verified in cooperation with Kaunas University of Technology.
Computational simulations
Structural behaviour assessed through engineering simulation before manufacturing.
Physical load testing
Wind and snow load performance evaluated through physical testing.
SIGMA profile geometry
A proprietary profile engineered for higher bending and torsional resistance than a standard C-profile.
Z330 / Magnelis corrosion-resistant steel
DX51D Z330 galvanized steel, or S350GD + ZM310 Magnelis®, per EN 10346.
Quality-controlled manufacturing in Lithuania
Structures are manufactured in Lithuania from European steel under controlled production processes.
Design Methodology
Wind and snow design methodology
Snow load reference
up to 1.6 kN/m²
Wind load reference
up to 24 m/s
Reference design loads documented in the SF-V2M36 technical sheet. Actual design loads are calculated per project site (snow zone, terrain, exposure) and are not a substitute for a project-specific structural calculation.
Standards
Standards and documentation referenced
| Standard | Scope |
|---|---|
| LST EN 1090-1:2009+A1:2011 | Execution of steel structures — conformity assessment of structural components |
| EN 1990:2002 | Eurocode: Basis of structural design |
| EN 1991-1-3 | Eurocode 1: Actions on structures — Part 1-3: Snow loads |
| EN 1991-1-4 | Eurocode 1: Actions on structures — Part 1-4: Wind actions |
| STR 2.05.04:2003 | Lithuanian technical construction regulation — Actions and Loads |
| ISO 9001:2015 | Quality management systems |
| ISO 14001:2015 | Environmental management systems |
| ISO 45001:2018 | Occupational health and safety management systems |
Standards are presented as documented in the supplied technical material. Not every certification applies to every product configuration — applicability is confirmed per project and per system during engineering review.
Profile Engineering
SIGMA profile comparison
~14%
~14% higher bending resistance than a standard C-profile
~23%
~23% higher torsional resistance than a standard C-profile
Comparative percentages come from the supplied structural evaluation against a standard C-profile and should not be presented as a universal guarantee for every configuration.
Materials
Material and corrosion protection
Up to ISO 9223 atmospheric corrosion category C4
Per ISO 1461 / ASTM A123 and ISO 3575
Coating category applies to the documented steel and coating options (DX51D Z330 / S350GD + ZM310 Magnelis®). Confirm the applicable category for your specific site exposure during engineering review.
Fasteners
Fastener information
Aluminium clamps
Manufactured from AlMg0.7Si (6060/6063) aluminium alloy per EN 573, with an anodised coating per ISO 7599:2018, thickness under 15 microns.
Connecting fasteners
Fasteners joining steel profiles are manufactured from A2-70 stainless steel per ISO 3506-1:2009, or galvanized steel where selected.
Manufacturing
Quality-controlled manufacturing
Structures are manufactured in Lithuania from European steel under controlled production processes, with management systems certified to ISO 9001:2015 (quality), ISO 14001:2015 (environmental), and ISO 45001:2018 (occupational health and safety).
Warranty
System warranty
SolarFrames provides a 10-year system warranty on mounting structures, subject to the installation and usage manual and the project-specific working drawings.
Coating warranty follows the documented ISO 9223 corrosion category for the selected steel/coating option.
Have a project-specific engineering question?
Send your site and load requirements and our engineering team will confirm the applicable configuration.
